About the Prius Hybrid Battery

Toyota Prius Hybrid Battery Replacement

At Motorcells, we offer as many options as we can for hybrid battery replacement.  For older, high mileage vehicles may recommend a renewed battery for a lower cost.  For a Prius to go the distance, you’ll want to put in a new battery.  Give us a call and we can help you decide.

New, Renewed, or Repaired

Factory new Prius hybrid battery replacements are guaranteed for life at Motorcells.  Not only that, we offer a battery buyback program if you car fails for other reasons, but your battery is still good. New Prius batteries cost the most, but last the longest.Renewed (refurbished) batteries typically carry a 3-year warranty and contain many if not all new battery cells and some replaced parts. Renewed Prius batteries cost a bit less than new, and will typically match the remaining life of your car. Repaired prius batteries carry a Motorcells 12-month warranty and are meant to get you back on the road in the most cost-effective way possible by switching out poorly performing cells and a few other important processes, including load balancing.  However, depending on the model year, this can be a less reliable alternative – as other cells can go bad in the future. Repaired Prius batteries cost the least, but offer variable longevity based on the year of the vehicle.

Product Details (2001-2015) – Prius Replacement Battery

The Toyota Prius (2001-2015) uses a Nickel-Metal Hydride (NiMH) battery pack located beneath the rear seat. This battery pack consists of 288 individual NiMH cells, arranged in 28 modules. The entire pack delivers a total voltage of 277.2 volts and a capacity of 6.5 amp-hours.

The primary function of the Prius NiMH battery is to assist the gasoline engine in powering the electric motor, significantly improving fuel efficiency. Additionally, it captures and stores regenerative braking energy generated when the car slows down or brakes, further enhancing efficiency.

Here’s a quick overview of the key specifications:

• Battery Type: Nickel-Metal Hydride (NiMH)
• Location: Underneath the rear seat
• Voltage: 277.2 volts
• Capacity: 6.5 amp-hours
• Weight: Approximately 85 pounds (38.6 kg)
• Dimensions: Roughly 34 inches long, 16 inches wide, and 7.5 inches tall (86.4 cm x 40.6 cm x 19.1 cm)

Please note: This information applies to Prius models from 2001 to 2015. For models after 2016, a different battery technology is used.

Product Details (2016-2024)

Newer Prius models (2016-2024) transitioned to a more advanced Lithium-Ion (Li-ion) battery pack. This battery is also located beneath the rear seat and plays a vital role in maximizing fuel efficiency and overall performance.

Compared to the NiMH battery, the Li-ion pack offers several advantages:

• Lighter weight: Typically ranging from 42 to 80 lbs (19 to 36 kg) depending on the model, contributing to improved fuel economy.
• Higher energy density: This allows for a similar battery size while delivering more power and efficiency.
• Extended lifespan: Li-ion batteries generally last longer than NiMH batteries.

Here’s a summary of the key specifications:

• Battery Type: Lithium-Ion (Li-ion)
• Location: Underneath the rear seat
• Voltage: (Details vary by model)
• Capacity: (Details vary by model)
• Weight: 42 – 80 lbs (19 – 36 kg) (varies by model)
• Dimensions: Similar to NiMH battery size, but slightly smaller and lighter (exact dimensions vary by model)

Remember: This information applies to Prius models from 2016 to 2024. Always consult your owner’s manual or a qualified mechanic to ensure you select the correct battery replacement for your specific Prius model year and trim level.
